NetBox for efficient infrastructure modeling

NetBox has been implemented in my environment for some time and has quickly become one of my favorite tools. It provides a comprehensive, structured, and view of networks, racks, devices, and IP addresses. Since then, it has allowed maintaining clean and current documentation that is actively used and refined.

NetBox is an open-source infrastructure resource modeling (IRM) tool that lets you document networks, racks, devices, and IP addresses in a structured and centralized way. Learn more on the official NetBox website.

This guide walks you through a practical installation of NetBox on a RHEL-based system using examplecorp.io as the domain and netbox as the hostname. The instructions assume a tech-savvy user familiar with Linux, PostgreSQL, and basic networking.

Installing PostgreSQL

Install PostgreSQL and initialize the database:

dnf install postgresql-server -y
postgresql-setup --initdb

Edit PostgreSQL configuration to use scram-sha-256 encryption:

cp /var/lib/pgsql/data/postgresql.conf /var/lib/pgsql/data/postgresql.conf.default
vi /var/lib/pgsql/data/postgresql.conf
# Set:
password_encryption = scram-sha-256

Update authentication for local connections:

cp /var/lib/pgsql/data/pg_hba.conf /var/lib/pgsql/data/pg_hba.conf.default
vi /var/lib/pgsql/data/pg_hba.conf
# Set:
# NetBox specific connections
host    netboxdb    netbox    127.0.0.1/32    scram-sha-256
host    netboxdb    netbox    ::1/128         scram-sha-256

# Default local connections
local   all         all       peer
host    all         all       127.0.0.1/32    ident
host    all         all       ::1/128         ident

Note: Make sure to place the NetBox-specific entries above the default authentication block in pg_hba.conf. This ensures NetBox uses scram-sha-256 without affecting other PostgreSQL users or services.

Start and enable PostgreSQL:

systemctl enable --now postgresql
systemctl status postgresql

Create the NetBox database and user:

sudo -u postgres psql
CREATE DATABASE netboxdb;
CREATE USER netbox WITH ENCRYPTED PASSWORD 'NetBoxRocks';
GRANT ALL PRIVILEGES ON DATABASE netboxdb TO netbox;
\q

Test the connection and change password if needed:

sudo -u postgres psql --username netbox --password --host localhost netboxdb
ALTER ROLE netbox WITH PASSWORD '{NEW_PASSWORD}';
\conninfo

Set up periodic backups using a tool like autopgsqlbackup.

Installing Redis

Redis serves as a fast in-memory store for caching and background task processing, helping NetBox run efficiently and handle asynchronous operations.

NetBox requires Redis for caching and background tasks:

dnf install redis -y
cp /etc/redis/redis.conf /etc/redis/redis.conf.default
vi /etc/redis/redis.conf
# Set:
requirepass {REDIS_PASSWORD}

systemctl enable --now redis
systemctl status redis

Note: You need to create a secure password for Redis yourself. A strong, 32-character password ensures your Redis instance is protected. On Linux, you can generate one using a command like openssl rand -base64 24. Make sure to use this same password in both the Redis configuration (requirepass) and the NetBox configuration.py file.

Verify Redis:

redis-cli
AUTH {REDIS_PASSWORD}
ping

Installing NetBox

Install required dependencies:

dnf install gcc libxml2-devel libxslt-devel libffi-devel libpq-devel openssl-devel redhat-rpm-config git -y

Create a dedicated NetBox user and directory:

useradd -r -d /opt/netbox -s /usr/sbin/nologin netbox
mkdir -p /opt/netbox
cd /opt/netbox
git clone -b master --depth 1 https://github.com/netbox-community/netbox.git .
chown -R netbox:netbox /opt/netbox

Copy the example configuration and generate a secret key:

cd /opt/netbox/netbox/netbox
sudo -u netbox cp configuration_example.py configuration.py
sudo -u netbox python3 ../generate_secret_key.py

Edit configuration.py to set domain, database, and Redis configuration:

ALLOWED_HOSTS = ['*']
CSRF_TRUSTED_ORIGINS = ['http://127.0.0.1']

DATABASE = {
    'NAME': 'netboxdb',
    'USER': 'netbox',
    'PASSWORD': '{POSTGRESQL_PASSWORD}',
    'HOST': 'localhost',
    'PORT': '',
    'CONN_MAX_AGE': 300,
}

REDIS = {
    'tasks': {
        'HOST': 'localhost',
        'PORT': 6379,
        'PASSWORD': '{REDIS_PASSWORD}',
        'DATABASE': 0,
        'SSL': False,
    },
    'caching': {
        'HOST': 'localhost',
        'PORT': 6379,
        'PASSWORD': '{REDIS_PASSWORD}',
        'DATABASE': 1,
        'SSL': False,
    }
}

SECRET_KEY = '{SECRET_KEY_CREATED_IN_LAST_STEP}'

Run the upgrade script to initialize NetBox:

sudo -u netbox /opt/netbox/upgrade.sh

Activate the Python virtual environment and create an admin user:

source /opt/netbox/venv/bin/activate
cd /opt/netbox/netbox
python3 manage.py createsuperuser
# Follow prompts for username, email, and password

Set up daily housekeeping via cron:

ln -s /opt/netbox/contrib/netbox-housekeeping.sh /etc/cron.daily/netbox-housekeeping

Configure Gunicorn:

sudo -u netbox cp /opt/netbox/contrib/gunicorn.py /opt/netbox/gunicorn.py
sudo -u netbox vi /opt/netbox/gunicorn.py
# bind = '127.0.0.1:8001'

Enable and start NetBox services:

cp -v /opt/netbox/contrib/*.service /etc/systemd/system/
systemctl daemon-reload
systemctl enable --now netbox netbox-rq
systemctl status netbox
systemctl status netbox-rq

Configuring NGINX as a Reverse Proxy

Install NGINX:

dnf install nginx -y
systemctl enable --now nginx

Create a configuration file /etc/nginx/conf.d/netbox.conf:

server {
   listen 80;
   listen 443 ssl;
   server_name netbox.examplecorp.io;

   ssl_certificate /etc/nginx/conf.d/netbox.examplecorp.io.crt;
   ssl_certificate_key /etc/nginx/conf.d/netbox.examplecorp.io.key;

   client_max_body_size 25m;

   location /static/ {
       alias /opt/netbox/netbox/static/;
   }

   location / {
       proxy_pass http://127.0.0.1:8001;
       proxy_set_header X-Real-IP $remote_addr;
       proxy_set_header Host $host;
       proxy_pass_header X-XSRF-TOKEN;
   }
}

Test and restart NGINX:

nginx -t
systemctl restart nginx

Troubleshooting

  • Database does not exist: Ensure DATABASE['NAME'] matches the database you created.
  • 502 Bad Gateway: Check ALLOWED_HOSTS and CSRF_TRUSTED_ORIGINS in configuration.py.
  • CSRF verification failed: Ensure NGINX headers and CSRF_TRUSTED_ORIGINS are correct.

Upgrading NetBox

When upgrading, check the release notes and follow multi-step upgrades for major version jumps (e.g., 3.x → 4.x). Use Git tags to check out releases:

sudo git fetch --tags
git describe --tags $(git rev-list --tags --max-count=1)
sudo git checkout v3.7.8   # Step 1
sudo git checkout v4.2.3   # Step 2

Ensure the correct Python version is used:

python3 --version
sudo dnf install python3.12
sudo alternatives --install /usr/bin/python3 python3 /usr/bin/python3.12 1
sudo alternatives --config python3

Run the upgrade script:

sudo ./upgrade.sh
sudo systemctl restart netbox netbox-rq

This setup has become a core part of my home lab, providing an organized, overview of all devices, IPs, and attributes. Its active maintenance ensures my infrastructure documentation is always accurate and easy to navigate.
